With the SC Venom, RS presents a state-of-the-art decoring machine that relies on proven technology and has been optimized through continuous development based on experience and customer feedback. It combines the best features of existing solutions and sets new standards in foundry technology. Developed for the efficient removal of sand cores from castings, the Shake Champion Venom combines performance, flexibility, and precision in a robust system.
Technical highlights at a glance
-
Oscillation amplitude: up to 14 mm for thorough cleaning
-
Frequency range: 10–25 Hz, ideal for different casting sizes and shapes
-
Maximum load: 160 kg (362 lbs)
-
Loading volume: 1000 × 800 × 400 mm – suitable for a wide range of workpiece dimensions
-
Workpiece clamping: manual or hydraulic, for maximum flexibility
-
Rotation: –170° to +170° for complete processing from all angles
-
Optional equipment: up to 4 hammers, cleaning air blade, sand conveyor
-
Overall dimensions: 4200 × 2500 × 3200 mm
Efficiency meets versatility
The SC Venom impresses with its high deburring performance and adaptability. Variable clamping systems and generous rotation options enable safe and efficient processing of a wide variety of castings. Optionally available hammers, air blades, and sand conveyors further increase the cleaning quality and significantly reduce the amount of rework required.
Made for modern foundries
With its robust design and practical functions, the SC Venom is the ideal solution for foundries that value quality, efficiency, and flexibility. Whether in series production or for complex individual parts, the machine delivers reliable, clean results and increases productivity in the long term.
